Leup Vx-5hd 4-20x52 Cds-zl2 Sf Dplx

Leupold VX-5HD 4-20x52 CDS-ZL2 Side Focus Duplex

The Leupold VX-5HD 4-20x52 CDS-ZL2 Side Focus Duplex riflescope is designed to provide versatility and precision for hunters and shooters. This scope combines high magnification power with a wide field of view, making it suitable for various environments and distances.

Key Features

The VX-5HD 4-20x52 CDS-ZL2 Side Focus Duplex riflescope offers several notable features that enhance its performance and user experience:

• High Magnification Power: The scope provides a maximum magnification of 20x and a minimum of 4x, allowing users to adapt to various distance requirements.
• Custom Dial System (CDS-ZL2): The CDS-ZL2 system offers two revolutions of elevation adjustment with a push-button ZeroLock system, ensuring precise and secure adjustments.
• Side Focus: The side focus adjusts the scope's parallax, reducing perceived movement and providing a clearer reticle.
• Professional-Grade Optical System: This system enhances light transmission and glare reduction, ensuring a clear image in challenging lighting conditions.
• Illuminated FireDot Duplex Reticle: The reticle is illuminated, providing better visibility in low-light conditions.
• Waterproof, Fogproof, and Shockproof: The scope is designed to withstand extreme conditions and maintain its performance.
• Light Management System: The scope includes Leupold’s Professional-Grade Optical System, which optimizes light transmission and glare reduction.

Specifications

• Battery Type: CR2032
• Daylight Bright Illumination: Yes
• Custom Dial Compatible: Yes
• Reticle Focal Plane: Second Focal Plane
• Reticle Type: Illuminated FireDot Duplex
• Adjustable Objective: No
• Switch Type: Push Button
• Elevation Adjustment Type: CDS-ZL2
• Elevation Adjustment Range (MOA): 75
• Elevation Adjustment Range (MIL): 22
• Elevation Adjustment Range (cm @ 100m): 218
• Elevation Adjustment Per Revolution: 20 MOA
• Elevation Dial Travel Limit: 38 MOA
• Windage Adjustment Type: Pop-Up Rezero
• Windage Adjustment Range (MOA): 75
• Windage Adjustment Range (MIL): 22
• Windage Adjustment Range (cm @ 100m): 218
• Windage Adjustment Per Revolution: 15 MOA
• Magnification Max: 20
• Magnification Min: 4
• Objective Lens Diameter (mm): 52
• Linear FOV Low Mag (ft@100yds): 28.4
• Linear FOV High Mag (ft@100yds): 7.7
• Angular FOV Low Mag (Degrees): 5.4
• Angular FOV High Mag (Degrees): 1.5
• Eye Relief Low Mag (in): 3.7
• Eye Relief High Mag (in): 3.8
• Minimum Parallax-Free Distance (yd): 50
• Battery Life (hr), Low Intensity: 1600
• Battery Life (hr), Medium Intensity: 1000
• Battery Life (hr), High Intensity: 300
• Number of Illum Settings: 8

Performance and Clarity

The Leupold VX-5HD 4-20x52 CDS-ZL2 Side Focus Duplex riflescope boasts high-definition lenses that ensure incredible clarity at all magnification levels. The scope's high-definition calcium-fluoride lenses provide exceptional resolution and clarity, ensuring that images are crisp and clear. Additionally, the Guard-ion hydrophobic lens coating sheds dirt and water, maintaining a clear and crisp image without the need for maintenance.

Durability and Construction

The VX-5HD 4-20x52 CDS-ZL2 Side Focus Duplex riflescope is designed and assembled in the USA, ensuring high-quality craftsmanship. It is the lightest, most rugged 5:1 riflescope in its class, making it suitable for demanding environments and conditions. Leupold's Lifetime Guarantee ensures that any issues with the scope will be addressed promptly and effectively.

Conclusion

The Leupold VX-5HD 4-20x52 CDS-ZL2 Side Focus Duplex riflescope is a versatile and reliable choice for hunters and shooters. Its combination of high magnification power, advanced optical systems, and rugged durability makes it a top contender in the market
